TP-Link CPE610 5GHz 300Mbps 23dBi CPE Outdoor Router

Antenna:2×2 MIMO antenna

Button:1 Reset Button

Frequency:5.15~5.85GHz

Data Rate: Up to 300Mbps (40MHz, Dynamic)
Up to 144.4Mbps (20MHz, Dynamic)
Up to 72.2Mbps (10MHz, Dynamic)
Up to 36.1Mbps (5MHz, Dynamic)

Wireless: Pharos MAXtream TDMA Technology
Selectable Channel Width: 5/10/20/40MHz
Auto Channel Selection
Transmit Power Control
Dynamic Frequency Selection(DFS)
WDS Enable/Disable

Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption,
64/128/152-bit WEP Encryption
SSID Broadcast Enable/Disable
Multi-SSID with VLAN Tagging(AP Mode only)
Distance/ACK Timeout Setting
Wireless MAC Address Filter
Wireless Advanced:
Beacon Interval/RTS Threshold/Fragmentation Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia

Network Standard: IEEE 802.11a/n

Encryption:Security: Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption,
64/128/152-bit WEP Encryption Security: SPI Firewall/ Ping Forbidden/DoS Protection

Ports:CPE610: 1 10/100Mbps Shielded Ethernet Port (LAN/POE)

POE ADAPTER:
1 10/100Mbps Shielded Ethernet Port (Power + Data)
1 10/100Mbps Shielded Ethernet Port (Data)

Others:Efficiency: >84.29%

Power Mode:Passive Power over Ethernet via LAN (+4,5pins; -7,8pins)
Voltage range: 16-27VDC
100-240VAC, 50/60Hz

InterfaceCPE610:1 10/100Mbps Shielded Ethernet Port (LAN/POE)
1 Reset Button

POE ADAPTER:
1 AC Jack with Earth Ground
1 10/100Mbps Shielded Ethernet Port (Power + Data)
1 10/100Mbps Shielded Ethernet Port (Data)

Dimension:CPE: 366 x 280 x 207 mm (14.4 x 11.0 x 8.1 in.)
POE ADAPTER: 85.8×43.9×29.7 mm

Color:White

Warranty:1 Year Warranty
